one person system
one person system
This system use for left / right and coherence brain wave experience : use CH 1 and CH 2.
System include head pad to connect electrode to forehead.
Cable connect to CH 1 ( Left ) and CH 2 ( Right ) input of IBVA unit.
IBVA4 DVD included application, QC plugin, AU plugin and sample files.
Following procedure is how to use CH 3 and CH 4 :
IBVA unit included extra input for CH 3 and CH 4.
Following operation need to be done by special electric technician.
Any system damage etc. is no guaranty.
Bluetooth IBVA unit has input pin connector for CH 3 and CH 4, located beside brain head band 6P connector pin.
This is input for 0 .. 5 V. ( don't put more than 5 V and/or less than 0 V )
You can connect any kind of signal to this pin.
Other brain wave amplifier output, GSR device output, heart amplifier output, etc.
Run IBVA4 and setup 4 ch device and select port for access CH 1, CH 2, CH 3, CH 4.
