test with IBVA4.5.6

use apple script to run  IBVA4/brain data sample/OpenLoopIBVAFileN

with Lab at Apple Inc.

OSX10.5

remote test speed

11 fps : Mac Pro : Two 3GHz Quad-Core Intel Xeon processors : Z0D8

11 fps: Mac Pro : Two 3GHz Dual-Core Intel Xeon processors : ZOD8

5fps: PowerMac G5 : G5@2.5GHz Quad Dual Core : M9592

3.8fps: PowerMac G5 : G5@2.7GHz DP : M9749

1.4fps : PowerMac G4 : G4@1.42GHz DP : M8841

3.8fps: 17" MacBook Pro : 2.4GHz Intel Core 2 Duo : MA897

3.6fps: 15" MacBook Pro : 2.4GHz Intel Core 2 Duo : MA896

5.5fps: Intel Core 2 Duo Mac Mini : Intel Core 2 Duo @ 2GHz : MB139

0.18fps: G4 Mac Mini : G4@1.42GHz : M9971

0.8fps: 20" iMac G5 : G5@2.1GHz : MA064

local test speed

10fps: iMac24" 2.8 GHz

5fps: Macbook Pro 2.0GHz

6fps: Macbook 2.16GHz

0.1fps: Powerbook G4 1GHz 17"

0.01fps: Powerbook G4 0.5GHz 15"

0.01fps: Powerbook G4 0.5GHz 14.1"

8 CPU : Quad-Core Intel Xeon processors test :

4 CPU : Dual-Core Intel Xeon processors

rec. mode and

open 4 Graphic window and start recording live movie as Motion JPEG A

MacBook Pro Core Duo 2.0 GHz : 1 fps

MacBook Core 2 Duo 2.16 GHz : 2.7 fps

iMac 24” Core 2 Extreme 2.8 GHz : 4.7 fps

----------------------------------------------------------------------

test with IBVA4.3.6 Universal.

play back "AlphaBig.ibva" speed.

speed is only open one window.

Dual Core and Dual processor systems one CPU usage is about 80 to 90 %.

other CPU is 10 to 20 %. this CPU can work for Quartz Composer, QT, MAX, etc.

RawGraph

30 fps (Intel iMac : 2GHz Dual Core)

30 fps (Macbook Pro: 2GHz Dual Core)

30 fps (Intel Mac MINI : 1.66GHz Dual Core)

16 fps (G4 powerbook : 1.5GHz)

26 fps (iMac : 2GHz)

27 - 29 fps (G5 Desktop : 1.83 GHz Dual processor)

WaterFall

10 fps (Intel iMac : 2GHz Dual Core)

10 fps (Macbook Pro : 2GHz Dual Core)

5 fps (Intel Mac MINI : 1.66GHz Dual Core)

3.5 fps (G4 powerbook : 1.5GHz)

8 fps (iMac : 2GHz)

8 fps  (G5 Desktop : 1.83 GHz Dual processor)

WaterFall BS

10 fps (Intel Mac Pro : 3GHz Quad (Xeon X 2) )

8 fps (Intel iMac : 2GHz Dual 2 Core)

5 fps (Intel iMac : 2GHz Dual Core)

5 fps (Macbook Pro : 2GHz Dual Core) (1920X1200 window size is same speed with external DVI monitor)

3 fps (Intel Mac MINI : 1.66GHz Dual Core)

1.2 fps (G4 powerbook : 1.5GHz)

3 fps  (iMac : 2GHz)

3 fps (G5 Desktop : 1.83 GHz Dual processor)

With HD QT play, speed IBVA4 window.

Open left, right and coherence brain sw mixer window and raw wave window on the Macbook, recording mode.

Play HD QT on the 1900 X 1200 DVI external monitor as full screen and full speed (24fps).

stop QT: 7 fps : (CPU 90% + 30%)

play QT (1920 X 1080 / 1080p 200MB, 24 fps / 8.62 Mbit / sec) : 2.3 fps : (CPU 90% + 90%)

play QT (1280 X 720 / 720p 130MB, 24 fps / 6 Mbit / sec) : 4.5 fps : (CPU 90% + 60%)

play QT (852 X 480 / 480p 83MB, 24 fps / 4 Mbit / sec) : 6.5 fps : (CPU 90% + 40%)

masahiro
